Infineon Technologies IRG4PH40UPBF information

Specifications
Documents & Media
Product Comparison
Related Products
Infineon Technologies IRG4PH40UPBF technical specifications, attributes, parameters and parts with similar specifications to Infineon Technologies IRG4PH40UPBF.
ParameterValue
Factory Lead Time 14 Weeks
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-247-3
Number of Pins 3
Transistor Element Material SILICON
Collector-Emitter Breakdown Voltage 1.2kV
Collector-Emitter Saturation Voltage 2.43V
Number of Elements 1
Test Conditions 960V, 21A, 10 u03a9, 15V
Turn Off Delay Time 220 ns
Operating Temperature -55u00b0C~150u00b0C TJ
Packaging Bulk
Published 2000
Part Status Last Time Buy
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Termination Through Hole
ECCN Code EAR99
Additional Feature LOW CONDUCTION LOSS
Voltage - Rated DC 1.2kV
Max Power Dissipation 160W
Current Rating 41A
Element Configuration Single
Power Dissipation 160W
Case Connection COLLECTOR
Input Type Standard
Turn On Delay Time 24 ns
Transistor Application POWER CONTROL
Rise Time 18ns
Polarity/Channel Type N-CHANNEL
Collector Emitter Voltage (VCEO) 3.1V
Max Collector Current 41A
JEDEC-95 Code TO-247AC
Voltage - Collector Emitter Breakdown (Max) 1200V
Turn On Time 49 ns
Vce(on) (Max) @ Vge, Ic 3.1V @ 15V, 21A
Turn Off Time-Nom (toff) 690 ns
Gate Charge 86nC
Current - Collector Pulsed (Icm) 82A
Td (on/off) @ 25u00b0C 24ns/220ns
Switching Energy 1.04mJ (on), 3.4mJ (off)
Gate-Emitter Voltage-Max 20V
Gate-Emitter Thr Voltage-Max 3V
Fall Time-Max (tf) 190ns
Height 20.3mm
Length 15.875mm
Width 5.3mm
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
