TE Connectivity AMP Connectors 5745784-4 information

Specifications
Documents & Media
Product Comparison
Related Products
TE Connectivity AMP Connectors 5745784-4 technical specifications, attributes, parameters and parts with similar specifications to TE Connectivity AMP Connectors 5745784-4.
ParameterValue
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Contact Plating Gold, Tin
Mount Through Hole
Mounting Type Through Hole, Right Angle
Contact Shape Round
Shell Material Steel
Dielectric Material Thermoplastic
Body Material Metal
Shell Material, Finish Steel, Tin Plated
PCB Mounting Orientation Right Angle
Contact Materials Phosphor Bronze
Operating Temperature -55u00b0C~105u00b0C
Packaging Tray
Published 2006
Series AMPLIMITE HD-20
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type Receptacle, Female Sockets
Number of Positions 37
Color Black
Number of Rows 2
Gender Receptacle
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Contact Type Signal
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.7432mm
Total Number of Contacts 37
Orientation Right Angle
Depth 18.97mm
Current Rating 6A
Shell Finish TIN
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Approval Agency CSA, UL
Number Of PCB Rows 2
PCB Contact Pattern STAGGERED
Body Breadth 0.497 inch
UL Flammability Code 94V-0
Lead Length 3.175mm
Empty Shell NO
Row Spacing 2.8448 mm
Flange Feature Housing/Shell (4-40)
ELV Compliant
Max Voltage Rating (AC) 125V
Plating Tin
Connector Style D-Sub
Number of Ports 1
Max Voltage Rating (DC) 125V
Sealable No
Shell Size, Connector Layout 4 DC C
Hole Diameter 3.18 mm
Backset Spacing 0.318 (8.08mm)
Preloaded Yes
Max Supply Voltage (DC) 125V
Max Supply Voltage (AC) 125V
Mating Connector Lock With
Features Ground Strap
Length 69.31mm
Contact Finish Thickness 30.0u03bcin 0.76u03bcm
PCB Thickness 1.58mm
Material Flammability Rating UL94 V-0
REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Lead Free
