Littelfuse Inc. V275LA40AP

Littelfuse Inc.

Manufacturer No:

V275LA40AP

Manufacturer:

Littelfuse Inc.

Cybertant No:

Package:

Datasheet:

ECAD Model:

Description:

VARISTOR 430V 6.5KA DISC 20MM

Quantity:

Unit Price: -

Ext Price: -

Delivery:

Payment:

In Stock : 1500

Minimum: 1 Multiples: 1

Want a lower wholesale price? Please send RFQ, we will respond immediately.

RFQ Now

Add to RFQ list

User Guide

Purchase & Inquiry

Package

Shipping Information

Shopping Manual

Purchase

You may place an order without registering to Cybertant.
We strongly suggest you sign in before purchasing as you can track your order in real time.

Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You'll receive an order information email in your inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping Cost

Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and country.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, and UPS.

Delivery Time

Once the goods are shipped, estimated delivery time depends on the shipping methods you chose:

FedEx International, 5-7 business days.

The following are some common countries' logistic time. transport

Step1：Prepare product
Step2：Vacuum packaging
Step3：Anti-static bag
Step4：Individual package
Step5：Packaging box
Step6：Barcode shipping label

Cybertant How to Login and Register Online

Cybertant How to Place an Order

Cybertant How to Request for Quote

Cybertant How to Use Manufacturers Page

Cybertant How to Use My Account

Littelfuse Inc. V275LA40AP information

Specifications

Documents & Media

Product Comparison

Related Products

Littelfuse Inc. V275LA40AP technical specifications, attributes, parameters and parts with similar specifications to Littelfuse Inc. V275LA40AP.

Parameter	Value
Factory Lead Time	18 Weeks
Mount	Radial, Through Hole
Mounting Type	Through Hole
Package / Case	Disc 20mm
Terminal Shape	WIRE
Operating Temperature	-55u00b0C~85u00b0C TA
Packaging	Bulk
Published	2005
Series	LA
JESD-609 Code	e3
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Number of Terminations	2
ECCN Code	EAR99
Temperature Coefficient	0.05 ppm/u00b0C
Terminal Finish	Matte Tin (Sn)
HTS Code	8533.40.40.00
Capacitance	900pF
Voltage - Rated DC	369V
Depth	5.6mm
Resistor Type	VARISTOR
Current Rating	100A
Voltage - Rated AC	275V
Rated Power Dissipation (P)	1W
Lead Pitch	8.5mm
Lead Length	25.4mm
Max Output Current	6.5kA
Number of Circuits	1
Max Voltage Rating (AC)	275V
Max Voltage Rating (DC)	369V
Lead/Base Style	Radial
Clamping Voltage	710V
Max Surge Current	6.5kA
Capacitance @ Frequency	900pF @ 1MHz
Energy	140J
Varistor Voltage (Min)	387V
Varistor Voltage (Typ)	430V
ESD Protection	No
Varistor Voltage	473V
Clamping Current	100A
Diameter	20mm
Height	26.5mm
Width	5.6mm
Thickness	5.6mm
REACH SVHC	Unknown
RoHS Status	ROHS3 Compliant
Lead Free	Lead Free
