Microchip Technology MCP23S18T-E/MJ information

Specifications
Documents & Media
Product Comparison
Related Products
Microchip Technology MCP23S18T-E/MJ technical specifications, attributes, parameters and parts with similar specifications to Microchip Technology MCP23S18T-E/MJ.
ParameterValue
Factory Lead Time 8 Weeks
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-VFQFN Exposed Pad
Number of Pins 24
Weight 928.191737mg
Number of I/Os 16
Operating Temperature -40u00b0C~125u00b0C
Packaging Tape & Reel (TR)
Published 2007
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
HTS Code 8542.39.00.01
Max Power Dissipation 700mW
Voltage - Supply 1.8V~5.5V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP23S18
Pin Count 24
Qualification Status Not Qualified
Output Type Open Drain
Power Supplies 2/5V
Interface SPI
Operating Supply Current 1mA
Number of Ports 2
Output Current 25mA
uPs/uCs/Peripheral ICs Type PARALLEL IO PORT, GENERAL PURPOSE
Number of Bits 16
Clock Frequency 10MHz
Interrupt Output Yes
Height Seated (Max) 0.9mm
Length 4mm
Width 4mm
RoHS Status ROHS3 Compliant
Lead Free Lead Free
