STMicroelectronics M74HC132RM13TR information

Specifications
Documents & Media
Product Comparison
Related Products
STMicroelectronics M74HC132RM13TR technical specifications, attributes, parameters and parts with similar specifications to STMicroelectronics M74HC132RM13TR.
ParameterValue
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Logic Level-High 1.5V ~ 4.2V
Logic Level-Low 0.3V ~ 1.5V
Operating Temperature -55u00b0C~125u00b0C
Packaging Tape & Reel (TR)
Series 74HC
JESD-609 Code e4
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Packing Method TAPE AND REEL
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 4.5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number M74HC132
Pin Count 14
Number of Outputs 1
Supply Voltage-Max (Vsup) 6V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Output Current 5.2mA
Propagation Delay 18 ns
Quiescent Current 1u03bcA
Turn On Delay Time 105 ns
Family HC/UH
Logic Function NAND
Number of Inputs 2
Logic Type NAND Gate
Number of Gates 4
Max Propagation Delay @ V, Max CL 18ns @ 6V, 50pF
Schmitt Trigger Input Yes
Features Schmitt Trigger
Height 1.65mm
Length 8.75mm
Width 4mm
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
