STMicroelectronics L6206D information

Specifications
Documents & Media
Product Comparison
Related Products
STMicroelectronics L6206D technical specifications, attributes, parameters and parts with similar specifications to STMicroelectronics L6206D.
ParameterValue
Factory Lead Time 12 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SOIC (0.295, 7.50mm Width)
Number of Pins 24
SwitchingFrequency 100kHz
Operating Temperature -25u00b0C~125u00b0C TJ
Packaging Tube
JESD-609 Code e4
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 24
ECCN Code EAR99
Resistance 300mOhm
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Applications DC Motors, Stepper Motors, Voltage Regulators
Voltage - Supply 8V~52V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 250
Number of Functions 1
Supply Voltage 48V
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number L6206
Pin Count 24
Number of Outputs 4
Output Voltage 60V
Max Output Current 5.6A
Operating Supply Voltage 48V
Supply Voltage-Min (Vsup) 8V
Number of Channels 2
Interface Logic
Analog IC - Other Type STEPPER MOTOR CONTROLLER
Nominal Supply Current 5mA
Output Configuration Half Bridge (4)
Output Current 2.8A
Output Current per Channel 2.8A
Collector Emitter Voltage (VCEO) 52V
Max Collector Current 2.8A
Voltage - Load 8V~52V
Fault Protection Current Limiting, Over Temperature, UVLO
Rds On (Typ) 300m u03a9
Motor Type Brushed
Load Type Inductive
Features Bootstrap Circuit
Height 2.65mm
Length 15.6mm
Width 7.6mm
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
