Microchip Technology HV20220FG-G
Microchip Technology HV20220FG-G thumbnail
Microchip Technology HV20220FG-G thumbnail
FREE SAMPLE

Microchip Technology HV20220FG-G

Microchip Technology

Manufacturer No:

HV20220FG-G

Manufacturer:

Microchip Technology

Cybertant No:

-

Package:

-

Datasheet:

-

ECAD Model:

-

Description:

Analog Switch ICs 200V 8Chl w/Latches

Quantity:

Unit Price: -

Ext Price: -

Delivery:

DHL TNT UPS FedEx SF Express

Payment:

PayPal Visa Discover Mastercard

Certification Certification Certification Certification Certification Certification Certification

In Stock : 2715

Minimum: 1 Multiples: 1

Want a lower wholesale price? Please send RFQ, we will respond immediately.

RFQ Now

Add to RFQ list

User Guide

Purchase & Inquiry
Package
Shipping Information
Shopping Manual
Purchase

You may place an order without registering to Cybertant.
We strongly suggest you sign in before purchasing as you can track your order in real time.

Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You'll receive an order information email in your inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping Cost

Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and country.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, and UPS.

Delivery Time

Once the goods are shipped, estimated delivery time depends on the shipping methods you chose:

FedEx International, 5-7 business days.

The following are some common countries' logistic time. transport
  • Prepare productStep1:Prepare product
  • Vacuum packagingStep2:Vacuum packaging
  • Anti-static bagStep3:Anti-static bag
  • Individual packageStep4:Individual package
  • Packaging boxStep5:Packaging box
  • Barcode shipping labelStep6:Barcode shipping label
Microchip Technology HV20220FG-G information

Specifications
Documents & Media
Product Comparison
Related Products
Microchip Technology HV20220FG-G technical specifications, attributes, parameters and parts with similar specifications to Microchip Technology HV20220FG-G.
ParameterValue
Factory Lead Time 7 Weeks
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-LQFP
Number of Pins 48
Weight 181.692094mg
Turn Off Delay Time 5 u03bcs
Operating Temperature 0u00b0C~70u00b0C TA
Packaging Tray
Published 2013
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 48
Resistance 38Ohm
Terminal Finish Matte Tin (Sn) - annealed
Applications Ultrasound
Additional Feature ALSO REQUIRES VPP (40V TO VNN +200V) AND VNN (-40V TO -160V) SUPPLY
Max Power Dissipation 1W
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number HV20220
Number of Outputs 8
Operating Supply Voltage 12V
Number of Channels 8
Max Supply Voltage 13.2V
Min Supply Voltage 4.5V
Analog IC - Other Type SINGLE-ENDED MULTIPLEXER
Operating Supply Current 7mA
Power Dissipation 1W
Max Supply Current 10u03bcA
Turn On Delay Time 5 u03bcs
Voltage - Supply, Single/Dual (u00b1) 40V~200V u00b140V~160V
Supply Type Dual
Max Dual Supply Voltage 200V
-3db Bandwidth 50MHz
On-State Resistance (Max) 38Ohm
Min Dual Supply Voltage 40V
Dual Supply Voltage 100V
Multiplexer/Demultiplexer Circuit 1:1
Off-state Isolation-Nom 33 dB
On-state Resistance Match-Nom 1.35Ohm
Switch Circuit SPST
Switch-on Time-Max 5000ns
Switch-off Time-Max 5000ns
Normal Position NO
Height 1.4mm
Length 7mm
Width 7mm
Radiation Hardening No
RoHS Status ROHS3 Compliant
