Hirose Electric Co Ltd FH12-12S-0.5SH(55)

Hirose Electric Co Ltd

Manufacturer No:

FH12-12S-0.5SH(55)

Manufacturer:

Hirose Electric Co Ltd

Cybertant No:

Package:

Datasheet:

ECAD Model:

Description:

FH12 Series 12 Position 0.5 mm Pitch Right Angle SMT FPC/FFC Connector

Quantity:

Unit Price: -

Ext Price: -

Delivery:

Payment:

In Stock : 200

Minimum: 1 Multiples: 1

Want a lower wholesale price? Please send RFQ, we will respond immediately.

RFQ Now

Add to RFQ list

User Guide

Purchase & Inquiry

Package

Shipping Information

Shopping Manual

Purchase

You may place an order without registering to Cybertant.
We strongly suggest you sign in before purchasing as you can track your order in real time.

Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You'll receive an order information email in your inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping Cost

Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and country.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, and UPS.

Delivery Time

Once the goods are shipped, estimated delivery time depends on the shipping methods you chose:

FedEx International, 5-7 business days.

The following are some common countries' logistic time. transport

Step1：Prepare product
Step2：Vacuum packaging
Step3：Anti-static bag
Step4：Individual package
Step5：Packaging box
Step6：Barcode shipping label

Cybertant How to Login and Register Online

Cybertant How to Place an Order

Cybertant How to Request for Quote

Cybertant How to Use Manufacturers Page

Cybertant How to Use My Account

Hirose Electric Co Ltd FH12-12S-0.5SH(55) information

Specifications

Documents & Media

Product Comparison

Related Products

Hirose Electric Co Ltd FH12-12S-0.5SH(55) technical specifications, attributes, parameters and parts with similar specifications to Hirose Electric Co Ltd FH12-12S-0.5SH(55).

Parameter	Value
Factory Lead Time	10 Weeks
Mount	Surface Mount
Mounting Type	Surface Mount, Right Angle
Material	Polyamide
Housing Material	Polyamide (PA), Nylon
Actuator Material	Polyphenylene Sulfide (PPS)
ActuatorColor	Brown
Contact Materials	Phosphor Bronze
Operating Temperature	-40u00b0C~85u00b0C
Packaging	Tape & Reel (TR)
Series	FH12
JESD-609 Code	e4
Pbfree Code	yes
Part Status	Active
Moisture Sensitivity Level (MSL)	1 (Unlimited)
Termination	Solder
ECCN Code	EAR99
Connector Type	FFC/FPC CONNECTOR
Number of Positions	12
Color	Beige, Brown
Number of Rows	1
Gender	Receptacle
Additional Feature	TAPE AND REEL PACKAGING
MIL Conformance	NO
DIN Conformance	NO
IEC Conformance	NO
Filter Feature	NO
Mixed Contacts	NO
Option	GENERAL PURPOSE
Current Rating (Amps)	0.5A
Pitch	0.020 0.50mm
Total Number of Contacts	12
Orientation	Right Angle
Depth	5.6mm
Current Rating	500mA
Reference Standard	UL, CSA
Contact Finish	Gold
Voltage - Rated AC	50V
Reliability	COMMERCIAL
Number Of PCB Rows	1
Lead Pitch	500u03bcm
PCB Contact Pattern	RECTANGULAR
Body Breadth	0.079 inch
UL Flammability Code	94V-0
Housing Color	Beige
Contact Style	BELLOWED TYPE
Contact Resistance	50mOhm
Insulation Resistance	500MOhm
Max Voltage Rating (AC)	50V
Max Current Rating	400mA
Contact Pattern	RECTANGULAR
Insertion Force-Max	ZIF N
Withdrawl Force-Min	ZIF N
Mating Cycles	20
Flat Flex Type	FFC, FPC
Cable End Type	Straight
Locking Feature	Flip Lock
Contact Location	Bottom
Features	Zero Insertion Force (ZIF)
Length	10.1mm
Width	10.1mm
Height Above Board	0.079 2.00mm
FFC, FCB Thickness	0.30mm
Material Flammability Rating	UL94 V-0
Radiation Hardening	No
REACH SVHC	No SVHC
RoHS Status	RoHS Compliant
Flammability Rating	UL94 V-0
Lead Free	Lead Free
