Infineon Technologies BTS409L1E3062ABUMA1 information

Specifications
Documents & Media
Product Comparison
Related Products
Infineon Technologies BTS409L1E3062ABUMA1 technical specifications, attributes, parameters and parts with similar specifications to Infineon Technologies BTS409L1E3062ABUMA1.
ParameterValue
Factory Lead Time 18 Weeks
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-5, D2Pak (4 Leads + Tab), TO-263BB
Number of Pins 5
Turn Off Delay Time 200 u03bcs
Operating Temperature -40u00b0C~150u00b0C TJ
Packaging Tape & Reel (TR)
Published 2013
Series PROFETu00ae
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Power Dissipation 18W
Terminal Position SINGLE
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 12V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PSSO-G6
Output Type N-Channel
Supply Voltage-Max (Vsup) 34V
Supply Voltage-Min (Vsup) 5V
Interface On/Off
Nominal Supply Current 1.8mA
Output Configuration High Side
Voltage - Supply (Vcc/Vdd) Not Required
Turn On Delay Time 200 u03bcs
Switch Type General Purpose
Halogen Free Not Halogen Free
Nominal Input Voltage 43V
Ratio - Input:Output 1:1
Voltage - Load 5V~34V
Fault Protection Current Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage, UVLO
Number of Drivers 1
Turn On Time 400 u03bcs
Output Peak Current Limit-Nom 7.5A
Rds On (Typ) 160m u03a9
Max Junction Temperature (Tj) 150u00b0C
Turn Off Time 400 u03bcs
Built-in Protections TRANSIENT; OVER CURRENT; OVER VOLTAGE; THERMAL; UNDER VOLTAGE
Output Current Flow Direction SOURCE
Features Auto Restart
Height 4.7mm
Length 9.9mm
Width 9.2mm
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
