Analog Devices Inc. AD8349AREZ
Analog Devices Inc. AD8349AREZ thumbnail
Analog Devices Inc. AD8349AREZ thumbnail
FREE SAMPLE

Analog Devices Inc. AD8349AREZ

Analog Devices Inc.

Manufacturer No:

AD8349AREZ

Manufacturer:

Analog Devices Inc.

Cybertant No:

-

Package:

-

Datasheet:

-

ECAD Model:

-

Description:

ANALOG DEVICES AD8349AREZ IC, QUADRATURE MODULATOR, SMD, 8349

Quantity:

Unit Price: -

Ext Price: -

Delivery:

DHL TNT UPS FedEx SF Express

Payment:

PayPal Visa Discover Mastercard

Certification Certification Certification Certification Certification Certification Certification

In Stock : 857

Minimum: 1 Multiples: 1

Want a lower wholesale price? Please send RFQ, we will respond immediately.

RFQ Now

Add to RFQ list

User Guide

Purchase & Inquiry
Package
Shipping Information
Shopping Manual
Purchase

You may place an order without registering to Cybertant.
We strongly suggest you sign in before purchasing as you can track your order in real time.

Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You'll receive an order information email in your inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping Cost

Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and country.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, and UPS.

Delivery Time

Once the goods are shipped, estimated delivery time depends on the shipping methods you chose:

FedEx International, 5-7 business days.

The following are some common countries' logistic time. transport
  • Prepare productStep1:Prepare product
  • Vacuum packagingStep2:Vacuum packaging
  • Anti-static bagStep3:Anti-static bag
  • Individual packageStep4:Individual package
  • Packaging boxStep5:Packaging box
  • Barcode shipping labelStep6:Barcode shipping label
Analog Devices Inc. AD8349AREZ information

Specifications
Documents & Media
Product Comparison
Related Products
Analog Devices Inc. AD8349AREZ technical specifications, attributes, parameters and parts with similar specifications to Analog Devices Inc. AD8349AREZ.
ParameterValue
Factory Lead Time 8 Weeks
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
Contact Plating Tin
Mount Surface Mount
Package / Case 16-TSSOP (0.173, 4.40mm Width) Exposed Pad
Number of Pins 16
Packaging Tube
JESD-609 Code e3
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Termination SMD/SMT
ECCN Code 5A991.B
Max Operating Temperature 85u00b0C
Min Operating Temperature -40u00b0C
HTS Code 8542.39.00.01
Max Power Dissipation 800mW
Voltage - Supply 4.75V~5.5V
Construction COMPONENT
Frequency 2.7GHz
Base Part Number AD8349
Function Modulator
Test Frequency 2.14GHz
Operating Supply Current 135mA
Nominal Supply Current 135mA
Max Supply Current 150mA
Output Power 5.1dBm
Bandwidth 170MHz
Max Supply Voltage (DC) 5.25V
Characteristic Impedance 50Ohm
Min Supply Voltage (DC) 4.75V
P1dB 5.6dBm
RF Frequency 700MHz~2.7GHz
LO Frequency 700MHz~2.7GHz
Modulation Technique QPSK
Noise Floor -156dBm/Hz
Height 1mm
Length 5mm
Width 4.4mm
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
