Home / All Products / Aluminum Electrolytic Capacitors / Rubycon 16TZV680M10X10.5
Rubycon 16TZV680M10X10.5
Rubycon 16TZV680M10X10.5 thumbnail
Rubycon 16TZV680M10X10.5 thumbnail
FREE SAMPLE

Rubycon 16TZV680M10X10.5

Rubycon

Manufacturer No:

16TZV680M10X10.5

Manufacturer:

Rubycon

Cybertant No:

-

Package:

-

Datasheet:

Datasheet

ECAD Model:

-

Description:

CAP ALUM 680UF 20% 16V SMD

Quantity:

Unit Price: -

Ext Price: -

Delivery:

DHL TNT UPS FedEx SF Express

Payment:

PayPal Visa Discover Mastercard

Certification Certification Certification Certification Certification Certification Certification

In Stock : 500

Minimum: 1 Multiples: 1

Want a lower wholesale price? Please send RFQ, we will respond immediately.

RFQ Now

Add to RFQ list

User Guide

Purchase & Inquiry
Package
Shipping Information
Shopping Manual
Purchase

You may place an order without registering to Cybertant.
We strongly suggest you sign in before purchasing as you can track your order in real time.

Means of Payment

For your convenience, we accept multiple payment methods in USD, including PayPal, Credit Card, and wire transfer.

RFQ (Request for Quotations)

It is recommended to request for quotations to get the latest prices and inventories about the part.
Our sales will reply to your request by email within 24 hours.

IMPORTANT NOTICE

1. You'll receive an order information email in your inbox. (Please remember to check the spam folder if you didn't hear from us).
2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping Cost

Shipping starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)
The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and country.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, and UPS.

Delivery Time

Once the goods are shipped, estimated delivery time depends on the shipping methods you chose:

FedEx International, 5-7 business days.

The following are some common countries' logistic time. transport
  • Prepare productStep1:Prepare product
  • Vacuum packagingStep2:Vacuum packaging
  • Anti-static bagStep3:Anti-static bag
  • Individual packageStep4:Individual package
  • Packaging boxStep5:Packaging box
  • Barcode shipping labelStep6:Barcode shipping label
Rubycon 16TZV680M10X10.5 information

Specifications
Documents & Media
Product Comparison
Related Products
Rubycon 16TZV680M10X10.5 technical specifications, attributes, parameters and parts with similar specifications to Rubycon 16TZV680M10X10.5.
ParameterValue
Factory Lead Time 18 Weeks
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Radial, Can - SMD
Terminal Shape WRAPAROUND
Number of Pins 2
Dielectric Material ALUMINUM (WET)
Surface Mount Land Size 0.406Lx0.406W 10.30mmx10.30mm
Lifetime @ Temp. 2000 Hrs @ 105u00b0C
Operating Temperature -55u00b0C~105u00b0C
Packaging Tape & Reel (TR)
Series TZV
Size / Dimension 0.394Dia 10.00mm
Tolerance u00b120%
JESD-609 Code e6
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin/Bismuth (Sn/Bi)
Applications Automotive
Capacitance 680u03bcF
Voltage - Rated DC 16V
Packing Method TR
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
Size Code 4141
Leakage Current 0.1088mA
Ripple Current 510mA
Polarization Polar
Life (Hours) 2000 hours
Tan Delta 0.16
Impedance 80mOhm
Ripple Current @ Low Frequency 510mA @ 120Hz
Ripple Current @ High Frequency 850mA @ 100kHz
Diameter 10mm
Height 10.5mm
Height Seated (Max) 0.413 10.50mm
Length 10.9mm
Width 10.3mm
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Ratings AEC-Q200
